SOLD - Ocean Going Tugboat
This US flagged, one of a kind, 4,200 HP ocean going tugboat is in ABS Lay-up status. It is a Shallow Notch ITB with plenty of power for the most difficult towing challenge with tremendous range. Note the lower wheelhouse Height of Eye is 24 feet, the upper wheelhouse with a 45 foot eye level. If you are in the market for this size US Flagged tugboat, you must consider this one at the top of the list. It is owned and rigidly maintained by a major US operator. The tug has COATED TANKS. Contact us and we will help you purchase this fine tugboat. Prospective purchasers must be pre-qualified by this Broker.
VESSEL IDENTIFIER: GT13
Price: U.S. $ 2,900,000.00 - FIRM
| Click Here for Photo Page 1 | Click Here for Photo Page 2 | Click Here for Photo Page 3 | Click Here for Photo Page 4 |
DIMENSIONS |
||
| Feet | Meters | |
| Length | 124 | 37.8 |
| Breadth | 31.6 | 9.63 |
| Max. Draft | 18.83 | 5.74 |
| Upper Pilot House | 45 Feet | 13.72 |
| Reported Speeds | 8
Knots Loaded Pushing 7.5 Knots Loaded Towing 10 Knots in Ballast Pushing 9.5 Knots Towing in Ballast |
|
| Fuel Consumption | 3,500
Gallons in Ballast 4,300 Gallons Loaded Per Day |
|
| Range | ||
| PARTICULARS | |
| Flag | US |
| Year Built | 1967 |
| Where Built | Gulfport Shipbuilding Corp |
| Registry | US |
| Class | ABS SS Due 6/30/01 |
| Certificates | |
| GRT | 197.02 |
| ITC Gross Tons | 436 |
MORE INFORMATION AND PICTURES BELOW
| Power | |
Main Engines |
2 - EMG12-645-E5 4,200 HP Total 19,700 Hrs since overhaul |
| Reduction | |
| Propeller | |
| Bollard Pull | |
Generators |
2 - 8V71 125 KW |
| Fuel Storage | 64,000 Gallons |
| Fresh Water | 1,000 Gallons |
| Deck Machinery | |
Towing Winch |
Single Drum Markey TYS-36 2,200 feet of 2 1/4 Wire Capacity |
| Other Winches | |
| Windlass | Yes - Anchor |
Navigation/Electronics |
||
| Lower Wheelhouse | Upper Wheelhouse | |
Radar |
Yes | Yes |
| Autopilot | ||
| GPS | ||
| Echo Sounder | ||
| Radios | ||
| Other Electronics | Too many to list | Too many to list |
| Accommodations | |
Rooms |
|
| Hospital | |
| Dining | One |
| Basic Galley Equipment | |
All photos Copyright 2001 Maritime Sales, Inc. and may not be copied or duplicated without the express permission of Maritime Sales, Inc.
