Seismic Cable or Supply Vessel
This well maintained Seismic Cable ABS vessel has a full compliment of electronics and all safety and fire fighting equipment. Having completed her annual ABS survey recently, she is ready for immediate work. The sale of the vessel does not include the Seismic Equipment shown in the photos. The equipment will be moved to another of Owners vessels.
VESSEL IDENTIFIER: ENC11
Price: U.S. $2,500,000.00 FIRM
DIMENSIONS |
||
| Feet | Meters | |
| Length | 201 | 61/2 |
| Width | 40 | 12.2 |
| Draft | 13.5 | 4.11 |
| Speed | 10 Knots | |
| Consumption | 4000 Gallons/24 hour day underway | |
| PARTICULARS | |
| Flag | US |
| Year Built/Rebuilt/Rebuilt | 1977/1992/2001 |
| Where Built | USA |
| Location | Texas |
| Class | ABS - Uninspected Oceanographic research Vessel |
| Next Special Survey | Dec. 31, 2011 |
| Load Line | ABS International Load Line |
| Last Dry-Dock | Jan. 20, 2010 |
| GRT | 291 US/ 1780 ITC |
| NRT | 198 US/ 534 ITC |
| Complement | 35 bunks in 10 Staterooms |
MORE INFORMATION AND PICTURES BELOW
| Power | |
Main Engines |
2 - EMD 12-645-C 800 RPM -1,500 HP each, 3,000 HP Total |
| Propellers | 2 - 3 Blade fixed in Kort Nozzles |
| Rudders | |
| Bow Thruster | Fixed Pitch 300 HP 8-71 Detroit Twin Disk Clutch |
| Generators | 2 - Caterpillar 3406B 290 KW |
| Windlass | |
| Steering | Sperry Cub Pump |
| Fuel Capacity | 142,000 Gallons |
| Lube Oil | 1,125 Gallons |
| Fresh Water | 64,688 |
| Water Maker | |
| Fuel Oil Seperator | Alfa Laval JWP-26-080 |
| Sanitation | 3,000 Gallon Holding Tank |
| Bollard Pull | |
| Seismic Cable | Not Included |
| Accommodations | |
Rooms |
19 Bunks in 10 Staterooms |
| Dining | Complete |
| Laundry | Complete 4 Units |
| Air conditioning | 7.5 Ton for Living quarters 3.5 Tons Bridge |
| SEISMIC EQUIPMENT | |
Gun Controller |
Syntron GCS90 |
| Firing System | Gator - Freewave 900 MHz Radio Network |
| Navigation | GPS-Trimble 4000 RS Receivers, Utilizing John Chance, Starfix differential correction |
| Compressor | 3 x Cherco Compressors 1,100 CFM with Caterpillar 399 Main Engines |
| Energy Source | Tuned Air gun Cluster array, total volume 4,140 cubic inch |
| Air Guns: | 30 - Bold 1900 "Long Life" (LLX) |
